DMS5-340 LCD Heating Magnetic Stirrer with Timer
DMS5-340 LCD Heating Magnetic Stirrer with Timer
- Ceramic-coated aluminum plate, with strong corrosion resistance and easy to clean.
- Corrosion-resistant full metal casing with excellent heat dissipation performance and reliable fire protection capabilities.
- Strong magnetic field, ideal for mixing viscous samples.
- High protection level: IP42.
- Heating modes:
A: Rapid heating mode
B: Standard heating mode
C: Stable heating mode
- To meet different customer needs.
- Safety lock to prevent accidental changes in operating status.
- Buzzer: When the machine malfunctions or the countdown for the timing function ends, the buzzer emits a "beep" sound to alert the user.
- Residual heat warning: When the plate temperature exceeds 50°C, heating will be automatically turned off, and the display will show a flashing "HOT" warning. Even when the power is turned off, the "HOT" warning will continue flashing on the display, alerting the user of the high temperature.
- Two independent safety circuits continuously monitor the device. In case of overheating, sensor malfunction, or system error, the machine will stop heating. If a short circuit occurs, the power will be automatically cut off, ensuring the operator's safety.
- DC brushless motor: Spark-free, long lifespan, low noise, maintenance-free, and smooth operation.
- LCD display shows set and real-time values for speed, time, and temperature, offering clear and intuitive readings.
- The timer function is available with a range of 1 minute to 99 hours and 59 minutes. Once the countdown ends, heating will stop, but stirring will continue to avoid thermal damage to the sample.
- Remote control function is available, allowing the device to be connected to a computer.
- The device comes with a variety of accessories, making it suitable for chemical synthesis laboratories in universities, research institutes, and enterprises.
- Safety temperature can be set.
PRODUCT PARAMETERS
PRODUCT PARAMETERS
Working plate size:Ø135mm (5 inch)
Plate Material:Aluminium with ceramic coating
Motor type:Brushless DC motor
Stirring positions:1
Maximum stirring volume [H₂O]:20L
Maximum stirrer size [length]:80mm
Speed range and step:50-1500rpm, increment 1rpm
Speed Display:LCD
Temperature display:LCD
Heating temperature range:Room temp-340°C, increment 1°C
Temperature control accuracy of heating liquid:±1°C(<100°C) ±1%(>100°C)
overheating protection:420°C
Temperature display accuracy:±0.1°C
External temperature sensor:PT1000(accuracy ±0.2°C)
Waste heat warning function:50°C
Data connection:RS232
Protection class:IP42
Timer function:1min-99h59min
Motor output power:10W
Power:650W
Heating output power:600W
Voltage, Frequency:100-120/200-240V, 50/60Hz
Dimensions [L × W × H]:270x175x98mm
Weight:2.2kg
Permissible ambient temperature and humidity:5-40°C, 80%RH
